ASUS Z11PR-D16 Intel® C621 LGA 3647 (Socket P) SSI EEB

Lisainfo

Depth

330 mm

Kaal

1.4 kg

Laius

305 mm

Package weight

2.42 kg

Storage temperature (T-T)

-40 - 70 °C

Operating temperature (T-T)

10 - 35 °C

Storage relative humidity (H-H)

20 - 90%

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

3

Harmonized System (HS) code

84733020

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Component for

Server

Ethernet interface type

Gigabit Ethernet

Processor manufacturer

Intel

On-board graphics card model

Aspeed AST2500

Maximum internal memory

512 GB

Motherboard chipset

Intel® C621

USB 2.0 connectors

2

Processor socket

LGA 3647 (Socket P)

System bus rate

10.4 GT/s

On-board graphics card memory

64 MB

Motherboard form factor

SSI EEB

Supported memory clock speeds

2400
2666

Supported memory types

DDR4-SDRAM

LAN controller

Intel® I350-AM2

ATX Power connector (24-pin)

Yes

Supported storage drive interfaces

SATA III

VGA (D-Sub) ports quantity

1

PCI Express x16 (Gen 3.x) slots

2

Parallel processing technology support

Not supported

Chassis intrusion connector

Yes

TPM connector

Yes

RAID levels

0
1
5
10

RAID support

Yes

Serial port headers

1

Supported DIMM module capacities

4GB
8GB
16GB
32GB
64GB

Number of processors supported

2

Maximum RDIMM memory

512 GB

Supported RDIMM module capacity

4GB
8GB
16GB
32GB

Supported LRDIMM clock speeds

2400
2666 MHz

Maximum LRDIMM memory

1.02 TB

PCI Express x8 (Gen 3.x) slots

4

Supported RDIMM clock speeds

2400
2666 MHz

Number of DIMM slots

16

Supported LRDIMM module capacity

32GB
64GB
