Biostar B550MXC PRO motherboard

Lisainfo

Depth

244 mm

Laius

244 mm

Ethernet LAN

Yes

Cables included

SATA

Ethernet LAN (RJ-45) ports

1

Windows operating systems supported

Windows 10 x64
Windows 11 x64

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

USB 2.0 ports quantity

2

Ethernet interface type

Gigabit Ethernet

Processor manufacturer

AMD

Maximum internal memory

128 GB

Motherboard chipset

AMD B550

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

1

HDMI ports quantity

1

Memory channels

Dual-channel

Audio chip

Realtek ALC897

Bundled software

BullGuard

USB 2.0 connectors

2

Processor socket

Socket AM4

Motherboard form factor

micro ATX

Motherboard chipset family

AMD

Audio output channels

7.1 channels

Supported memory clock speeds

1866
2133
2400
2666
2933
3200
4533

Unbuffered memory

Yes

Memory slots type

DIMM

Number of memory slots

4

Supported memory types

DDR4-SDRAM

LAN controller

Realtek RTL8111H

Front panel audio connector

Yes

Number of COM connectors

1

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

Supported storage drive interfaces

M.2, SATA III

PS/2 ports quantity

1

ECC сompatibility

ECC & Non-ECC

Drivers included

Yes

Maximum number of SMP processors

1

Number of SATA III connectors

8

TPM connector

Yes

Clear CMOS jumper

Yes

Supported storage drive types

HDD & SSD

Number of M.2 (M) slots

2

HDCP

Yes

EPS power connector (8-pin)

Yes

Front panel connector

Yes

DirectX version

12.0

S/PDIF out connector

Yes

WiFi-AP antenna jack

2
