TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall Plate Access Point

Lisainfo

Depth

86 mm

Kõrgus

20 mm

Laius

143 mm

Package weight

300 g

Quantity per pack

1 pc(s)

Product colour

Valge

Security algorithms

64-bit WEP
128-bit WEP
152-bit WEP
802.1x RADIUS
HTTPS
SNMP
SNMPv3
SSH
WPA
WPA-Enterprise
WPA-PSK
WPA2
WPA2-Enterprise
WPA2-PSK

Access Control List (ACL)

Yes

Storage temperature (T-T)

-40 - 70 °C

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

5 - 90%

Reset button

Yes

Universal Plug and Play (UPnP)

Yes

Ethernet LAN (RJ-45) ports

4

Antennas quantity

2

LED indicators

LAN
Power
Status
WAN
WLAN

MAC address filtering

Yes

Quality of Service (QoS) support

Yes

Web-based management

Yes

Ethernet LAN data rates

10
100
1000 Mbit/s

Cabling technology

10/100/1000Base-T(X)

Networking standards

IEEE 802.1x
IEEE 802.3af
IEEE 802.3at
IEEE 802.11a
IEEE 802.11ac
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

Package width

117 mm

Package depth

184 mm

Package height

33 mm

Compliance certificates

CE
Federal Communications Commission (FCC)
RoHS

Harmonized System (HS) code

85176990

Sustainability compliance

Yes

Antenna type

Internal

Quick start guide

Yes

Wi-Fi Multimedia (WMM)/(WME)

Yes

Antenna gain level (max)

4 dBi

Power over Ethernet (PoE)

Yes

MIMO

Yes

Power consumption (typical)

24.4 W

Frequency band

2.4 - 5 GHz

Package type

Box

BeamForming

Yes

Maximum data transfer rate

1167 Mbit/s

Mounting kit

Yes

2.4 GHz

Yes

5 GHz

Yes

Placement

Wall

Antenna features

Integrated antenna

Virtual LAN features

Port-based VLAN
VLAN mapping

MIMO type

Multi User MIMO

Maximum data transfer rate (5 GHz)

867 Mbit/s

6 GHz

No

Maximum data transfer rate (2.4 GHz)

300 Mbit/s

VLAN support

Yes

Power over Ethernet (PoE) type supported

Active PoE
Passive PoE

Syslog

Yes

Automatic channel selection

Yes

Number of SSID supported

16

Service Set Identifier (SSID) features

Multiple SSIDs

WAN connection

Ethernet (RJ-45)

Cable lock slot

Yes

Band steering

Yes

Transmitting power (FCC)

21 dBm

Transmitting power (CE)

20 - 23 dBm

Wireless isolation

Yes

Rate limiting

Yes

Automatic channel scanning

Yes

Remote Authentication Dial-In User Service (RADIUS)

Yes
