PIR motion sensor with external sensor 360s 800W MCE32

Description:

PIR motion sensor with external sensor 800W 360 ° MCE32

The sensor is used to automatically control lighting or other electrical equipment which saves energy consumption. Lighting is switched on a PIR motion sensor which works on an infrared. It allows for the inclusion of lighting under the influence of motion of the object emits heat. Built-in light sensor allows you to turn the sensor function when working in daylight.

- Power supply: 220-240V
- Power Frequency: 50 / 60Hz
- Viewing angle: 120 ° Wall-installation / 360 °-installation Ceiling
- Reach (SENS): from 3m to 6m at 24 ° C (optional)
- Range of light sensitivity: 10LUX / 2000LUX (adjustable)
- Operating temperature: -20 / + 40 ° C
- Lighting time: 5s, 30s, 1min, 3min, 5min, 8min (adjustable)
- Power consumption: about 0.5W
- Max. power sensor:
  - 800W (filament bulbs)
  - 200W (energy-saving lamps and LED)
- Installation height: 1.8-2.5m (wall mounting)
- Mounting height: 2.2-4m (ceiling mount)
- IP20

Designation:
