CyberPower OLS3000EA-DE uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2700 W 7 AC outlet(s)

Lisainfo

Depth

416 mm

Kaal

26 kg

Kõrgus

337 mm

Laius

169 mm

Product colour

Must

Storage temperature (T-T)

-20 - 50 °C

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

20 - 90%

Storage relative humidity (H-H)

10 - 90%

Package width

295 mm

Package height

458 mm

Compliance certificates

CE
RoHS

USB port

Yes

Harmonized System (HS) code

8504408590

Warnings

Do not disassemble the unit housing, there may be a risk of electric shock.
Keep away from sources of fire and water.
Use the appliance in well-ventilated areas to avoid overheating.

Housing material

Metal

Display type

LCD

Battery technology

Sealed Lead Acid (VRLA)

Form factor

Tower

Non-operating altitude

0 - 1500 m

Operating altitude

0 - 1500 m

Battery recharge time

4 h

Response time

0 ms

Cable length

1.5 m

Number of batteries supported

3

Output power

2700 W

Input frequency

50/60 Hz

Charging current

1.5 A

Surge energy rating

370 J

Audible alarm(s)

Yes

Maximum current

13.04 A

Power plug

C20 coupler

Power protection features

Input fuse
Over current
Overload
Short circuit

Power factor

0.9

AC outlets quantity

8 AC outlet(s)

Output frequency

50/60 Hz

Surge protection

Yes

Input operation voltage (max)

300 V

Input operation voltage (min)

190 V

Output power capacity

3 kVA

Output operation voltage (min)

208 V

UPS topology

Double-conversion (Online)

Output operation voltage (max)

240 V

Waveform

Pure sine

AC outlet types

C13 coupler
C19 coupler
Terminal

EMI/RFI noise filtering

Yes

Audible alarm modes

Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm

Number of input phases

1

Emergency Power Off (EPO)

Yes

Typical backup time at half load

13.1 min

Typical backup time at full load

4.3 min

Replacement battery cartridge

BPSE72V40A

Output voltage Total Harmonic Distortion (THD)

5%

Emergency Power Off (EPO) connector

Yes

Crest factor

3:1

Input power factor

0.98

Efficiency (ECO mode)

95%
