Infosec INF_661062 Backup Power Supply UPS X1+ 700, 700VA, 360W, 2× FR/Schuko

Lisainfo

Depth

286 mm

Kaal

3.9 kg

Kõrgus

138 mm

Laius

96 mm

Product colour

Must

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%

Cables included

USB cable, Input power cable

Compliance certificates

RoHS

USB port

Yes

Warnings

Do not disassemble the unit housing, there may be a risk of electric shock.
Keep away from sources of fire and water.
Use the appliance in well-ventilated areas to avoid overheating.

Manual

Yes

Certification

CE

USB 2.0 ports quantity

1

Battery capacity

7 Ah

Battery technology

Lead-acid

USB port type

USB Type-B

Form factor

Tower

Battery voltage

12 V

Battery recharge time

8 h

Noise level

40 dB

Output power

360 W

Input frequency

50/60 Hz

Audible alarm(s)

Yes

Automatic Voltage Regulation (AVR)

Yes

Power protection features

Over power
Overvoltage protection
Surge protection
Telephone/ADSL Line Protection

AC outlets quantity

2 AC outlet(s)

Cold start

Yes

Output frequency

50/60 Hz

Surge protection

Yes

Input operation voltage (max)

290 V

Input operation voltage (min)

162 V

Output power capacity

700 VA

Output operation voltage (min)

240 V

UPS topology

Line-Interactive

Output operation voltage (max)

220 V

Waveform

Modified sine wave

AC outlet types

Schuko
Type E (FR)

Audible alarm modes

Alarm when on battery, Fault, Overload alarm, Low battery alarm

Number of input phases

1

Number of output phases

1

Typical backup time at half load

10 min

Typical backup time at full load

22 min

Output voltage regulation

-10 - 10%
