92,7 € (KM-ga)
Kuumakse al. 7.88€
Tarne 3-6 tööpäeva
Lisa lemmikuks
Viide:
H810M-X WIFI
Bränd:
ASRock
0.92 kg
Lisa võrdlusesse0
Kirjeldus

X Series motherboard offers a compact, high-value solution, balancing performance, versatility, and reliability for both professional and daily tasks.

The ASRock X-Series motherboard provides a high-value solution, balancing performance and versatility within a compact form factor. It’s highly capable in handling a wide range of tasks, from professional productivity to everyday usage, striking an excellent balance between affordability, reliability, and efficiency.

High Speed M.2 Solution

Hyper M.2 Gen4 x4
Supports PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.

Intelligent Cooling Design

Aluminum Heatsink
The first thing that catches the eye is the optimized Aluminum Heatsink Design. Heatsinks are crucial for efficient heat dissipation, especially during heavy workloads like gaming or productivity tasks. Motherboard that built with heatsinks can effectively manage thermal performance, hence ensure system stability and durability effortlessly.

Dual Band 802.11ac WiFi
No one has time for weak WiFi signals and sluggish internet! That's why this motherboard comes with a 802.11ac WiFi (2.4G / 5G WiFi) module which supports wireless networks and Bluetooth.

Dragon 2.5 Gb/s LAN
The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you’ll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups.

Front USB 3.2 Gen1 Type-C
Front USB 3.2 Gen1 Type-C header delivers up to 5 Gbps data transfer rate and next generation reversible USB design to the front panel of computer case.

POLYCHROME RGB
This motherboard features onboard RGB headers and addressable RGB headers that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects.
*The addressable RGB LED header supports WS2812B addressable RGB LED strip (5V/Data/GND), with a maximum power rating of 3A (5V), a max of 80 LEDs and length within 2 meters.
*The RGB LED header supports standard 5050 RGB LED strip (12V/G/R/B), with a maximum power rating of 3A (12V) and length within 2 meters.

SignalRGB
SignalRGB unifies your RGB devices, offering seamless customization, game-reactive effects, macro automation, and system monitoring. The official partnership empowers ASRock motherboards with advanced lighting control, enhances compatibility with a diverse range of RGB devices, and provides greater customization flexibility.

3 Graphics Outputs
Complete with all three types of most used connectors! Packed with a D-Sub + DisplayPort + HDMI combo.
*Supported only with processors with integrated graphics. Please check CPU support list from each motherboard webpage.

Auto Driver Installer
No need to worry about lack of disk drive! Asrock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD.
step1: Install Auto Driver Installer
step2: Update drivers needed
step3: Done!

  • Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851)
  • 6+1+1+1+1 Power Phase
  • 2 x DDR5 DIMMs
  • Supports Dual Channel, up to 6400
  • 1 PCIe 4.0 x16, 1 PCIe 4.0 x1
  • Graphics Output Options: 1 HDMI, 1 DisplayPort, 1 D-Sub
  • Realtek ALC897 7.1 CH HD Audio Codec
  • 4 SATA3
  • 1 Hyper M.2 (PCIe Gen4x4)
  • 1 USB 3.2 Gen1 Type-C (Front)
  • 4 USB 3.2 Gen1 (2 Rear, 2 Front)
  • 6 USB 2.0 (4 Rear, 2 Front)
  • Realtek 2.5G LAN
  • Dual Band 802.11ac Wi-Fi + Bluetooth

This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.

Loe edasiShow less
Toote üksikasjad
H810M-X WIFI

Lisainfo

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 2.0 ports quantity
4
Bluetooth
Jah
HDMI ports quantity
1
USB 2.0 connectors
1
Motherboard chipset family
Intel
Unbuffered memory
Yes
Memory slots type
DIMM
Number of chassis fan connectors
1
Front panel audio connector
Yes
CPU fan connector
Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
BIOS type
UEFI AMI
Number of HDDs supported
4
PS/2 ports quantity
1
VGA (D-Sub) ports quantity
1
ECC сompatibility
Non-ECC
12V power connector
Yes
RGB LED pin header
Yes
TPM connector
Yes
DisplayPorts quantity
1
PCI Express x16 (Gen 4.x) slots
1
Number of M.2 (M) slots
1
Supported memory clock speed (max)
6400 MHz
Number of CPU fan connectors
1
PCI Express x1 (Gen 4.x) slots
1
BIOS memory size
256 Mbit
Bluetoothi versioon
5.0
Traadita võrk
Jah
Wi-Fi standardid
802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
Etherneti kohalik võrk
Jah
Laius
220 mm
Sügavus
193 mm
Ethernet-liidese tüüp
2.5 Gigabit Ethernet
Ühilduvad operatsioonisüsteemid
Microsoft Windows 11 64-bit
Etherneti LAN (RJ-45) pordid
1
Mikrofoni sisend
Jah
Sertifitseerimine
- FCC, CE
- ErP/EuP ready (ErP/EuP ready power supply is required)
Toetatud Windowsi operatsioonisüsteemid
Windows 11 x64
Komponent jaoks
PC
Protsessori pesa
LGA 1851 (Socket V1)
Ühilduvad protsessorisarjad
Intel Core Ultra (Series 2)
Emaplaadi vormitegur
Micro ATX
Toetatud mälutüübid
DDR5-SDRAM
Maksimaalne sisemine mälu
128 GB
Ühikuid saatmiskarbis
1
Ühiku arvutatud maht
0.004032 cubm
ATX toitepistik (24-kontaktiline)
Yes
EPS-toitepistik (8-kontaktiline)
Yes
Ühikuid ühe aluse kohta
0
Heli väljundkanalid
7.1 channels
Toetatavate salvestusseadmete arv
5
Toetatud salvestusketaste liidesed
M.2,SATA III
Liinisisend
Jah
Toetatud salvestusketaste tüübid
HDD & SSD
Mälupesade arv
2
Toote värv
Multicolour
Paralleeltöötlustehnoloogia tugi
Not supported
DisplayPorti versioon
1.4
Parim Wi-Fi standard
Wi-Fi 5 (802.11ac)
Mälu kanalid
Dual-channel
Protsessori tootja
Intel
LAN kontroller
Dragon RTL8125BG
Emaplaadi kiibistik
Intel H810
SATA III ühenduste arv
4
