ASRock Z890 Pro RS - Motherboard

Lisainfo

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

Windows operating systems supported

Windows 11 x64

Ethernet interface type

2.5 Gigabit Ethernet

Processor manufacturer

Intel

Maximum internal memory

256 GB

Motherboard chipset

Intel Z890

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

1

HDMI ports quantity

1

Memory channels

Dual-channel

Operating system architecture

64-bit

Audio chip

Realtek ALC897

Thunderbolt 4 ports quantity

2

USB 3.2 Gen 2x2 Type-C ports quantity

1

USB 2.0 connectors

2
4

Processor socket

LGA 1851 (Socket V1)

Compatible processor series

Intel Core Ultra (Series 2)

Motherboard form factor

ATX

Motherboard chipset family

Intel

Audio output channels

7.1 channels

Unbuffered memory

Yes

Memory slots type

DIMM

Number of memory slots

4

Supported memory types

DDR5 non-ECC

LAN controller

Dragon RTL8125BG

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

2

BIOS type

UEFI AMI

Supported storage drive interfaces

Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)

Number of SATA III connectors

4

RGB LED pin header

Yes

Supported memory clock speed (max)

9066 MHz

PCI Express x16 (Gen 5.x) slots

1

Line-out

Yes

MIC input

1

Number of USB 3.2 Gen 1 ports

2

Addressable LED connectors

3

Flashback BIOS button

Yes

AIO pump fan connector

1

8-pin power connector 12 V

2

Chassis fan connector (4-pin)

5

SPI TPM socket

1

LED and speaker power socket

1

Speaker output

1

DisplayPort 1.4

1

External antenna connector

Yes, x 2
