ASRock Z890M Riptide WiFi Motherboard

Lisainfo

Depth

244 mm

Laius

305 mm

Ethernet LAN

Yes

Cables included

ARGB Splitter Cable x 1
SATA III 2 pcs.
Thermistor Cable x 1

Wi-Fi standards

802.11 axe
IEEE 802.11a
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11b
IEEE 802.11be
IEEE 802.11g
IEEE 802.11n

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

Ethernet LAN (RJ-45) ports

1

Windows operating systems supported

Windows 10 x64
Windows 11 x64

Wireless statistics

Yes

Wi-Fi antenna

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

Wi-Fi frequency

2,4 Ghz / 5 GHz / 6 GHz

Wi-Fi

Yes

Ethernet interface type

2.5 Gigabit Ethernet

Processor manufacturer

Intel

Maximum internal memory

256 GB

Bluetooth version

5.4

Bluetooth

Yes

Motherboard chipset

Intel Z890

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

2

HDMI ports quantity

1

Memory channels

Dual-channel

Audio chip

Realtek ALC1220

Headphone outputs

1

USB 2.0 connectors

2

Number of Thunderbolt 4 USB-C ports

2

USB 2.0 Type-A ports quantity

2

Processor socket

LGA 1851 (Socket V1)

Compatible processor series

Intel Core Ultra (Series 2)

Motherboard form factor

ATX

Motherboard chipset family

Intel

Audio output channels

7.1 channels

Unbuffered memory

Yes

Memory slots type

DIMM

Number of memory slots

4

Supported memory types

DDR5-SDRAM

LAN controller

Killer E3100G

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

2

BIOS type

UEFI AMI

Supported storage drive interfaces

M.2, SATA III

Microphone in

Yes

PCI Express x1 (Gen 3.x) slots

1

ECC сompatibility

Non-ECC

Maximum number of SMP processors

1

Number of SATA III connectors

4

RGB LED pin header

Yes

TPM connector

Yes

Supported storage drive types

HDD & SSD

RAID levels

0
1
5
10

PCI Express x16 (Gen 4.x) slots

1

Number of M.2 (M) slots

1

RAID support

Yes

USB 3.2 Gen 2 (3.1 Gen 2) connectors

1

Thunderbolt headers

1

PCI Express x16 (Gen 5.x) slots

1

Number of antenna connectors

2

Certificates

CE
ErP/EuP ready
FCC

SPDIF optical output

Y

Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports

1

Intel Extreme Memory Profile (XMP) version

3.0

AIO pump fan connector

1

8-pin power connector 12 V

2

Pump connector

1

Chassis fan connector (4-pin)

4

Motherboard

Yes
