Intel Core i7-12700 processor 25 MB Smart Cache Box

Lisainfo

Processor cores

12

Harmonized System (HS) code

8542310001

Warnings

Avoid shocks and drops so as not to damage delicate components.
Do not touch the processor pins to avoid electrostatic damage.

Processor model

i7-12700

Processor manufacturer

Intel

Processor cache type

Smart Cache

Processor family

Intel® Core™ i7

Processor cache

25 MB

Processor threads

20

Processor generation

12th gen Intel® Core™ i7

On-board graphics card

Yes

Discrete graphics card model

Not available

Discrete graphics card

No

On-board graphics card model

Intel UHD Graphics 770

Maximum internal memory

128 GB

Processor base power

65 W

Efficient cores

4

Maximum turbo power

180 W

Performance cores

8

Memory channels

Dual-channel

Embedded options available

No

Execute Disable Bit

Yes

ECC

Yes

Performance-core base frequency

2.1 GHz

Maximum number of PCI Express lanes

20

On-board graphics card OpenGL version

4.5

On-board graphics card DirectX version

12.0

Number of execution units

32

Intel® Quick Sync Video Technology

Yes

CPU configuration (max)

1

Commodity Classification Automated Tracking System (CCATS)

G167599

Enhanced Intel SpeedStep Technology

Yes

Intel 64

Yes

Processor operating modes

64-bit

Processor socket

LGA 1700

PCI Express slots version

4.0
5.0

Intel® vPro™ Platform Eligibility

Yes

Intel® AES New Instructions (Intel® AES-NI)

Yes

Intel® Secure Key

Yes

Supported instruction sets

AVX 2.0
SSE4.1
SSE4.2

Intel® OS Guard

Yes

Processor package size

45 x 37.5 mm

Intel® Hyper Threading Technology (Intel® HT Technology)

Yes

Thermal Monitoring Technologies

Yes

Memory bandwidth (max)

76.8 GB/s

Performance-core boost frequency

4.8 GHz

Maximum internal memory supported by processor

128 GB

Memory types supported by processor

DDR4-SDRAM
DDR5-SDRAM

OpenCL version

2.1

Status

Launched

Launch date

Q1'22

Bus type

DMI4

Processor codename

Alder Lake

Box

Yes

Memory bandwidth supported by processor (max)

76.8 GB/s

Maximum number of DMI lanes

8

On-board graphics card outputs supported

DisplayPort 1.4a
Embedded DisplayPort (eDP) 1.4b
HDMI 2.1

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card dynamic frequency (max)

1500 MHz

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card base frequency

300 MHz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

120 Hz

On-board graphics card ID

0x4680

Number of displays supported (on-board graphics)

4

On-board graphics card maximum resolution (DisplayPort)

7680 x 4320 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2160 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

5120 x 3200 pixels

Multi-Format Codec Engines

2

Direct Media Interface (DMI) Revision

4.0

PCI Express configurations

1x16+1x4
2x8+1x4

Scalability

1S

Idle States

Yes

Market segment

Desktop

Use conditions

PC/Client/Tablet
Workstation

Tjunction

100 °C

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel® Volume Management Device (VMD)

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Thread Director

Yes

Intel® Speed Shift Technology

Yes

Intel® Turbo Boost Technology

2.0

Mode-based Execute Control (MBE)

Yes

Intel® Clear Video HD Technology (Intel® CVT HD)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Turbo Boost Max Technology 3.0

Yes

Intel® Boot Guard

Yes

Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0

Yes

Intel® Control-flow Enforcement Technology (CET)

Yes

Graphics output

eDP 1.4b, DP 1.4a, HDMI 2.1

Export Control Classification Number (ECCN)

5A992CN3

Intel® Optane™ Memory Ready

Yes

Intel Stable Image Platform Program (SIPP)

Yes

Intel Trusted Execution Technology

Yes

Target market

Gaming, Content Creation

Intel® Total Memory Encryption

Yes

Intel® Turbo Boost Max Technology 3.0 frequency

4.9 GHz
