TP-Link T2U Nano

Характеристики

Depth

7.1 mm

Height

18.6 mm

Width

15 mm

Package weight

90 g

Product colour

Black

Security algorithms

64-bit WEP
128-bit WEP
WPA-PSK
WPA2-PSK

Storage temperature (T-T)

-40 - 70 °C

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

5 - 90%

Quick installation guide

Yes

Wi-Fi standards

802.11a
802.11b
802.11g
Wi-Fi 4 (802.11n)
Wi-Fi 5 (802.11ac)

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

Top Wi-Fi standard

Wi-Fi 5 (802.11ac)

Antenna design

Internal

Networking standards

IEEE 802.1x
IEEE 802.11a
IEEE 802.11ac
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

Windows operating systems supported

Windows 7
Windows 8
Windows 8.1
Windows 10
Windows XP

Mac operating systems supported

MacOS

Package width

138 mm

Package depth

128 mm

Package height

30 mm

Compliance certificates

CE
Federal Communications Commission (FCC)
RoHS

Harmonized System (HS) code

85176990

Sustainability compliance

Yes

Modulation

16-QAM
64-QAM
256-QAM
CCK
DBPSK
DQPSK
OFDM

WLAN data transfer rates supported

11
54
150
200
433 Mbit/s

Frequency range

2.4 - 5 GHz

Operating modes

Infrastructure mode

Antenna direction type

Omni-directional

Wi-Fi

Yes

Component for

PC/Laptop

Antenna

Yes

Internal

No

Maximum data transfer rate

433 Mbit/s

Interface

WLAN

Host interface

USB

USB version

2.0

Connectivity technology

Wired

USB powered

Yes

Transmitting power (FCC)

20 dBm

Transmitting power (CE)

20 dBm

Resource CD

Yes
