Mercusys AX1800 Dual-Band WiFi 6 Router

Характеристики

Product type

Tabletop router

Depth

157.2 mm

Height

45 mm

Width

175.6 mm

Product colour

Black

Power source type

DC

Security algorithms

WPA
WPA2
WPA3

Firewall

Yes

DMZ support

Yes

Access Control List (ACL)

Yes

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

5 - 90%

Reset button

Yes

WPS push button

Yes

MU-MIMO technology

Yes

Ethernet LAN

Yes

Port triggering

Yes

Ethernet LAN interface type

Gigabit Ethernet

Port forwarding

Yes

AC adapter included

Yes

Cables included

LAN (RJ-45)

Quick installation guide

Yes

Wi-Fi standards

802.11a
802.11b
802.11g
Wi-Fi 4 (802.11n)
Wi-Fi 5 (802.11ac)
Wi-Fi 6 (802.11ax)

WLAN data transfer rate (first band)

1201 Mbit/s

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

WLAN data transfer rate (second band)

300 Mbit/s

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

WLAN data transfer rate (max)

1500 Mbit/s

DHCP client

Yes

DHCP server

Yes

Ethernet LAN (RJ-45) ports

3

Antennas quantity

4

Antenna design

External

DSL WAN

No

SIM card slot

No

3G/4G USB modem compatibility

No

Ethernet WAN

Yes

LED indicators

Power, WLAN

Firewall security

SPI Firewall, IP and MAC Address Binding

Number of guest networks (2.4 GHz)

1

Ethernet LAN data rates

10
100 Mbit/s
1000 Mbit/s

Cabling technology

10/100/1000Base-T(X)

Networking standards

IEEE 802.11a
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

USB port

No

WAN connection type

RJ-45

Warnings

Avoid contact with liquids as this may cause electric shock.
Do not open the appliance housing - risk of electric shock.
The product may emit radio waves that may interfere with other electronic devices.

Number of guest networks (5 GHz)

1

Network address translation (NAT)

Yes

Wall mountable

Yes

Wi-Fi Multimedia (WMM)/(WME)

Yes

Detachable antenna(s)

No

Antenna gain level (max)

5 dBi
