ASUS RS700A-E12-RS12U Socket SP5 Rack (1U) Black, Steel

Характеристики

Depth

842.5 mm

Weight

14.9 kg

Height

43.9 mm

Width

449 mm

Package weight

19.9 kg

Product colour

Black
Steel

Storage temperature (T-T)

-40 - 60 °C

Operating temperature (T-T)

10 - 35 °C

Operating relative humidity (H-H)

20 - 90%

Storage relative humidity (H-H)

20 - 90%

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

3

Built-in processor

No

LED indicators

Yes

Ethernet LAN data rates

1000 Mbit/s
10000

Warnings

Do not disassemble the unit yourself.
Do not throw into regular trash, product requires special disposal.
The product may contain components that are harmful to health, use caution when handling.

Certification

BSMI, CE, CB, C-Tick, FCC(Class A)

AC input frequency

50/60 Hz

AC input voltage

100 - 240 V

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Ethernet interface type

10 Gigabit Ethernet
Gigabit Ethernet

Processor manufacturer

AMD

Power supply

2600 W

Processor family

AMD

On-board graphics card model

Aspeed AST2600

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Processor socket

Socket SP5

PCI Express slots version

4.0
5.0

On-board graphics card memory

64 MB

Compatible processor series

AMD EPYC 9004

Supported memory types

DDR5-SDRAM

LAN controller

Intel X710-AT2
Intel® I350-AM4

Supported storage drive interfaces

Serial ATA, Serial Attached SCSI (SAS)

VGA (D-Sub) ports quantity

1

Supported storage drive types

HDD & SSD

Number of M.2 (M) slots

2

Number of storage drives supported

14

PCI Express x16 slots

1

Cooling type

Active

PCI Express x4 slots

1

AMD Opteron series

9000

Supported DIMM module capacities

32GB
64GB
128GB

Chassis type

Rack (1U)

80 PLUS certification

80 PLUS Platinum

Maximum RDIMM memory

3 TB

PCI Express x8 slots

1

IPMI LAN (RJ-45) port

Yes

Number of DIMM slots

24

Storage drive sizes supported

2.5
M.2

Redundant power supply (RPS) support

Yes

Number of redundant power supplies supported

2

Hot-swap HDD bays

Yes

Integrated BMC with IPMI

Yes
