Intel Core i7-11700K processor 3.6 GHz 16 MB Smart Cache Box

Характеристики

Processor cores

8

Harmonized System (HS) code

85423119

Warnings

Avoid shocks and drops so as not to damage delicate components.
Do not touch the processor pins to avoid electrostatic damage.
Ensure that the processor is adequately cooled to prevent overheating.

Processor model

i7-11700K

Component for

PC

Processor manufacturer

Intel

Processor cache type

Smart Cache

Processor family

Intel® Core™ i7

Processor cache

16 MB

Processor threads

16

Processor boost frequency

5 GHz

Processor generation

11th gen Intel® Core™ i7

On-board graphics card

Yes

Discrete graphics card model

Not available

Discrete graphics card

No

On-board graphics card model

Intel UHD Graphics 750

Maximum internal memory

128 GB

Memory channels

Dual-channel

Embedded options available

No

Execute Disable Bit

Yes

ECC

No

Configurable TDP-down

95 W

Maximum number of PCI Express lanes

20

On-board graphics card OpenGL version

4.5

Number of execution units

32

Intel® Quick Sync Video Technology

Yes

CPU configuration (max)

1

On-board graphics card 4K support

Yes

Commodity Classification Automated Tracking System (CCATS)

G167599

Configurable TDP-down frequency

3.1 GHz

Intel Clear Video Technology

Yes

Enhanced Intel SpeedStep Technology

Yes

Intel 64

Yes

Processor operating modes

64-bit

Processor socket

LGA 1200 (Socket H5)

PCI Express slots version

4.0

System bus rate

8 GT/s

Processor lithography

14 nm

Intel® vPro™ Platform Eligibility

Yes

Intel® AES New Instructions (Intel® AES-NI)

Yes

Intel® Secure Key

Yes

Supported instruction sets

AVX-512
AVX 2.0
SSE4.1
SSE4.2

Processor ARK ID

212047

Intel® OS Guard

Yes

Processor package size

37.5 x 37.5 mm

Intel® Hyper Threading Technology (Intel® HT Technology)

Yes

Thermal Monitoring Technologies

Yes

Memory bandwidth (max)

50 GB/s

Supported memory types

DDR4-SDRAM

Maximum internal memory supported by processor

128 GB

Memory types supported by processor

DDR4-SDRAM

Status

Launched

Launch date

Q1'21

Memory bandwidth supported by processor (max)

50 GB/s

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card dynamic frequency (max)

1300 MHz

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card base frequency

350 MHz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

60 Hz

On-board graphics card ID

0x4C8A

Number of displays supported (on-board graphics)

3

On-board graphics card maximum resolution (DisplayPort)

5120 x 3200 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2160 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

5120 x 3200 pixels

PCI Express configurations

1x8+3x4
1x16+1x4
2x8+1x4

Scalability

1S

Idle States

Yes

Market segment

Desktop

Use conditions

PC/Client/Tablet

Tjunction

100 °C

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Turbo Boost Technology

2.0

Intel® Clear Video HD Technology (Intel® CVT HD)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Turbo Boost Max Technology 3.0

Yes

Intel® Boot Guard

Yes

Export Control Classification Number (ECCN)

5A992CN3

Intel® Optane™ Memory Ready

Yes

Thermal Design Power (TDP)

125 W

Processor base frequency

3.6 GHz

Maximum on-board graphics card memory

64 GB

Memory clock speeds supported by processor

3200 MHz

Intel® InTru™ 3D Technology

Yes

Intel Software Guard Extensions (Intel SGX)

No

Intel Stable Image Platform Program (SIPP)

Yes

Intel® Identity Protection Technology (Intel® IPT)

Yes

Intel® Thermal Velocity Boost

No

Intel Trusted Execution Technology

Yes

Intel® Turbo Boost Technology 2.0 frequency

4.9 GHz

Target market

Gaming, Content Creation

Intel® Turbo Boost Max Technology 3.0 frequency

5 GHz

Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0

Yes
