be quiet! BN337 power supply unit 850 W 20+4 pin ATX ATX Black

Характеристики

Depth

160 mm

Weight

1.81 kg

Height

86 mm

Width

150 mm

Package weight

3.52 kg

On/off switch

Yes

Product colour

Black

Operating temperature (T-T)

0 - 40 °C

Cables included

CPU, SATA

Package width

248 mm

Package depth

328 mm

Package height

102 mm

Compliance certificates

CE
Federal Communications Commission (FCC)
RoHS
UKCA
WEEE

Warnings

Avoid contact of the product with water or other liquids.
Do not open the case - risk of electric shock.
The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.

Sustainability compliance

Yes

Sustainability certificates

ENERGY STAR
ErP
Triman

AC input frequency

50/60 Hz

AC input voltage

100 - 240 V

Input current

10/5 A

Package type

Box

Mean time between failures (MTBF)

100000 h

Warranty period

10 year(s)

EPS power connector (8-pin)

Yes

Products per shipping (inner) case

6 pc(s)

Cooling type

Active

Noise level

22.1 dB

Efficiency

92.3%

Purpose

PC

Shipping (inner) case length

65.1 cm

Shipping (inner) case width

28.2 cm

Shipping (inner) case height

34.6 cm

Number of fans

1 fan(s)

Fan diameter

13.5 cm

Peak power

920 W

80 PLUS certification

80 PLUS Platinum

Total power

850 W

Power protection features

Over current
Overheating
Over power
Over voltage
Short circuit
Under voltage

Bearing technology

FDB

Supported motherboard form factors

ATX, micro ATX, Mini-ATX

Fan speed

0 - 2100 RPM

Combined power (+3.3V)

150 W

Max output current (+5V)

25 A

Max output current (+3.3V)

25 A

Combined power (+5V)

150 W

Hold time

19.2 ms

Combined power (+12V)

849.6 W

Max output current (+5Vsb)

3 A

Max output current (-12V)

0.5 A

ATX version

3.1

Power supply unit (PSU) form factor

ATX

Cable tie(s) included

Yes

Number of SATA power connectors

9

PCI Express power connectors (6+2 pin)

4

Motherboard power connector

20+4 pin ATX

SATA power cable length

550
700
850 mm
1000 mm

Peripheral (Molex) power cable length

850 mm
1000 mm

CPU power cable length

70 cm

Cabling type

Fully-Modular

Motherboard power cable length

60 cm

PCI Express power connectors (16-pin)

1

EPS power connector (4+4 pin)

Yes

PCI Express power cable length

60 cm

Power factor

0.99

Number of PATA power connectors

2

Max output current (+12V1)

70.8 A

EPS version

2.92

Shipping (inner) case net weight

22.7 kg
