ASUS Prime B450M-K II AMD B450 Socket AM4 micro ATX

Характеристики

Depth

244 mm

Width

244 mm

Ethernet LAN

Yes

Cables included

SATA

Ethernet LAN (RJ-45) ports

1

Windows operating systems supported

Windows 7 x64
Windows 10 x64

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

Wi-Fi

No

Ethernet interface type

Gigabit Ethernet

Processor manufacturer

AMD

Maximum internal memory

64 GB

Motherboard chipset

AMD B450

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

3

Audio chip

Realtek ALC887-VD2

Headphone outputs

1

USB 2.0 connectors

2

Processor socket

Socket AM4

Compatible processor series

2nd Generation AMD Ryzen™ 3
2nd Generation AMD Ryzen™ 5
2nd Generation AMD Ryzen™ 7
AMD Ryzen™ 3
AMD Ryzen™ 5
AMD Ryzen™ 7
AMD Ryzen™ Threadripper™
AMD Ryzen™ Threadripper™: The Second Generation

Motherboard form factor

micro ATX

Motherboard chipset family

AMD

Audio output channels

7.1 channels

Supported memory clock speeds

2133
2400
2666
2800
2933
3000
3200

Unbuffered memory

Yes

Memory slots type

DIMM

Number of memory slots

2

Supported memory types

DDR4-SDRAM

Number of chassis fan connectors

2

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

BIOS type

UEFI AMI

Supported storage drive interfaces

M.2, PCI Express 3.0, Serial ATA III

PS/2 ports quantity

2

VGA (D-Sub) ports quantity

1

Microphone in

Yes

PCI Express x16 (Gen 3.x) slots

2

Number of SATA III connectors

4

RAID levels

0
1
10

DVI-D ports quantity

1

PCI Express x1 (Gen 2.x) slots

2

Audio connector

Yes

S/PDIF out connector

Yes
